Module Street Light SL-26 High Lumens Outdoor Lighting Waterproof 100W LED Die Casting Aluminium Street Light Fixtures

  • 1
  • 2

Brand Name : Die-casting Man

Model Number : YASL-26-100

Certification : CE, RoHs, ENEC, CB

Place of Origin : CHINA

MOQ : 1pc

Price : Negotiable

Payment Terms : T/T, 30% T/T as deposit, 70% T/T balance before delivery(EXW) or against shipping documents(FOB Ningbo), L/C

Supply Ability : 30000pcs/month

Delivery Time : 7-10 days based on order QTY

Packaging Details : 1pc/bag/foam/carton, pallet optional

Power : 80-120W

Optical Effect : 130~180 lm/w(Optional)

Material : Die Casting Aluminium

Power Factor : PF≥0.95

Protectin Grade : IP66

Protection level : IK08/09/10

Color rendering index : Ra≥70

Size : 510x370x150 mm

Gross Weight : 4.7kgs

Net Weight : 4.1kgs

Contact Now

Module Street Light SL-26

Products Description
Model
Installation Pipe Diameter
Product Size(mm)
L
W
H
YSSL-26-50
Φ60
449
360
152
YSSL-26-100
Φ60
529
360
152
YSSL-26-150
Φ60
609
360
152
YSSL-26-200
Φ60
689
360
152
YSSL-26-250
Φ60
769
360
152
YSSL-26-300
Φ60
849
360
152
Materials
Housing:ADC12;Cover:Toughened Glass；Screws:304stainless screws
Color
Other colors can be customized according to the international color card
Led brand
LUMILEDS,OSRAM,CREE option
Led Specifications
3030,5050 option
Optical effect
130～140 lm/w,140～150 lm/w,150～160 lm/w,160～170 lm/w,170～180 lm/w,170～180 lm/w option
Color Temperature
2700K,3000K,3500K,4000K,5000K,5700K,6500K option(Reference:Energy Star)
color rendering index
Ra≥70；Ra≥80；Ra≥90 option
Optics
TYPEI,TYPEII,TYPEIII,TYPEV,TYPEIV option
Driver bran
OSRAM/TRIDONIC/MEAN WELL/SOSEN/INVENTRONICS
Input Voltage
AC90～305V
Security level
ClassI/ClassII/Class1/Class2 option
Frequency Range
43～63Hz
Power Factor
PF≥0.95
Working conditions Range
-30 to 45℃,20% to 90%RH
Dimming mode
Time control/0-10V/ Opticalcontrol/DALI option
Lightning protection
10KV/15KV/20KV option
Warranty
5/8 year option
Protection
Overcurrent/Short circuit/Over temperature
Protection level
IP66;IK08/09/10
Certifications
ENEC;CE;CB;IEC;RoHs;TUV;Lightning protection;LM-79;LM-80;IP66
Module Street Light SL-26 High Lumens Outdoor Lighting Waterproof 100W LED Die Casting Aluminium Street Light Fixtures

Installing Ways: Both Horizontal and Vertical available and adjustable angle-15°to 15°
Module Street Light SL-26 High Lumens Outdoor Lighting Waterproof 100W LED Die Casting Aluminium Street Light Fixtures

Material:Die casting Aluminum body
Module Street Light SL-26 High Lumens Outdoor Lighting Waterproof 100W LED Die Casting Aluminium Street Light Fixtures
Advantages
Standard modular street lamps Optional Glass Module and PC lens module Adjustable Mounting Direction and angle ± 15 ° Tool-free
detachable construction Top ventilation dust-proof net design Optical effect:130～190 lm/W Optional horizontal installation
